After
- Machine type
Blowers Series1
- O&U Themes
Cost optimisation
Efficiency
- Complexity3/3
- Machine Sub-assemblyOven
Description
-Average life 18 000 hours.
-Better resistance to elongation, resulting in a more efficient synchronisation at preform transfer.
-Ossicles profile optimized to eliminate friction.Ring in polyacetal for improved contact with the tensioner wheel.
-Installation possible on SBO 4, SBO 6, SBO 10, SBO 16, and SBO 24/26.Additional parts like turning ramps will be replaced.
Key message
Machine application
All S1 except blowers with track ovens, circular ovens, bi-cavity ovens
Benefits
-This new solution greatly reduces the elongation of the chain and increase its service life by 50%.
-Improved stability over the time, of the preform conveying (better accuracy at preform loading, unloading, transfer at oven outlet)
-Less maintenance, thanks to the elimination of the lubrication of the ball joint.
